STM32F4 Core 32 Board parts list

Parts List

Description Type Quantity Reichelt Ref Mouser Ref Digikey Ref
STM32F4 Board Mainboard 1 511-STM32F407G-DISC1
74HC595 IC 1 74HC 595 595-SN74HC595N
74HCT541 IC 1 74HCT 541 595-SN74HCT541N
BC337 Transistor 1 BC 337-16 512-BC33740TA
4*1kΩ Resistor 1 1.0k 652-4605X-AP1-102LF
1kΩ Resistor 2 1/4W 1.0k 291-1K-RC
2,2kΩ Resistor 4 1/4W 2.2k 291-2.2K-RC
10kΩ Resistor 1 1/4W 10k 291-10K-RC
10kΩ Pot Pot 2 PT 6-L 10K 72-T70XX-10K
1N4148 Diode 1 1N 4148 512-1N4148
100nF Cap Ceram 2 Z5U-2,5 100n 80-C412C104K5R
DIP16 Socket Socket 1 GS 16 653-XR2A-1611-N
DIP20 Socket Socket 1 GS 20 653-XR2A-2001-N
DIL 2×5 Socket Socket 10 PFL 10 538-87834-1019
DIL 2×8 Socket Socket 2 PFL 16 538-87834-1619
DIL 25×2 Socket Socket 2 BL 2X25G 2,54 649-66953-025LF
SD Card Socket Socket 1 SD-RSMT-2-MQ

Mouser Project Cart: https://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=e9426707a4
